Fireclay Insulation Brick
Fire clay insulation brick is red and light weight.It be used as inner lining of industry kilns and furnace.The fireclay insulation brick have low thermal conductivity for greater energy efficiency.
Color : Red
Package: carton,pallet
Usage: Industrial furnace and equipment
Overview of Fireclay Insulation Brick
Fireclay insulation brick is made of chamotte clay and fire clay materials with alumina content ≥30%.This brick is very light weight,density is from 0.5 to 1.3 g/cm3.Fireclay insulation brick working temperature is from 950C to 1200C.
Available Grade
The fireclay insulation brick are available in different sizes and density.
Temperature(C) | 900,950,1000,1100,1200 |
Bulk Density(g/cm3) | 0.6,0.7,0.8,1.0,1.1,1.2,1.3 |
Features
Light weight and low thermal conductivity
Good insulation performance
Accurate size and good quality
Low impurities
Long service life
Application
Fire clay insulation brick have various using area,mainly the safety lining of industry kilns and furnace,such as blast furnace,hot blast stoves,electric arc furnace,cement kiln,heat reaction chamber and other thermal industrial equipment.
How to Order Light weight Fireclay Insulation Bricks?
If you need insulation brick or need specific dimensions & shapes,please contact us to Take A Quote,we will offer more details to help.
Cargoes will be deliveried by sea.
Payment Term: TT
Lead Time:Usually about 5-10 days,because of the production schedule,please contact us to confirm directly.
Data Sheet
Item | B1 | B2 | B3 |
Temp(C) Reheating Shrinkage less than 2.0% | 900 | 1000 | 1100 |
Bulk Density(g/cm3) | ≥0.6 | ≥0.7 | ≥0.7 |
Cold Crushing Strength(kg/cm2) | ≥25 | ≥25 | ≥25 |
Thermal Conductivity(kcal/m,hr,C)at 350C | ≥0.17 | ≥0.18 | ≥0.20 |
