Calcium Silicate Board
Calcium silicate board also known as calsil insulation board, it is high strength,durable and light weight insulation materials. Calsil board widely used as backup insulation lining.It is easy to install and flexible,makes it an good choose in insulation.
■ Color: White
■ Package: Carton,Pallet
■ Usage: Thermal insulation,fireproof,sound proof
Overview of Calcium Silicate Board
Calcium silicate board are made of a mixture of Portland cement,fine silica,special cellulose fibers and unique fillers to improve durability,strength,moisture and fire resistance.
Calcium silicate board is free of soluble ingredients or free alkali.If exposed to moisture,the board could recover on drying out,and the strength keep no change.
Calcium silicate panels using life will not be effected by time in usage,it only could be effected by the supporting durability and the fastening products.
Calcium silicate board insulation are widely used in various range such as steel,ferrous and non-ferrous foundry,metallurgy,ceramics and related industry.
Available grade and size
Calcium Silicate Board Size(can be customized) | ||
Temperature | Size | |
650 or 1050 | L*W(mm) | Thickness(mm) |
400*250 | 25-150 | |
600*300 | 25-150 | |
600*150 | 25-150 | |
610*150 | 25-150 | |
500*500 | 25-130 | |
1050 | 600*600 | 25-130 |
1000*500 | 25-130 | |
1200*600 | 25-130 | |
1000*1000 | 25-130 | |
1200*1200 | 25-130 | |
Advantages
Free of asbestos and fibre
Light weight and easy to install
Fireproof,sound absorption and heat insulation
Long service life,unaffected by sunlight and steam
Good heat insulation performance and low thermal conductivity
Applications
For external and internal walls&ceiling
Used as fire protective and insulation solution
The sub-roof board and the underlay board for floor and wall tile
Decorative usage
How to Order Calcium Silicate Board ?
If you need calcium silicate insulation board or need specific dimensions & shapes,please contact us to Take A Quote,we will offer more details to help.
Normal cargo will be delivered by sea transportation.
Payment Term:TT
Lead Time: Please contact us to confirm.
Data Sheet
Items | Calcium silicate board |
Classified Tem (℃) | 1000℃/1832℉ |
Density (kg/m³) | 200-500 |
Bending Strength (Mpa) | ≥0.5 |
Conpressive Strength (Mpa) | ≥0.9 |
Thermal Conductivity （w/m.k） | ≤0.056 |
Linear Shrinkage （%） | ≤1.5 |
Max. working Tem. (℃) | 1000/1050/1100 |
Size (mm) | 1000*500/600*300 |
